Power Divider
High-Performance Broadband Dividers
Microstrip Power Dividers
Our series of miniaturized microstrip power dividers is engineered for high-density electronic systems. Available with SMA or N-type connectors, these dividers provide high isolation and low insertion loss, making them essential for signal distribution and combining in modern RF chains.
Key Applications:
Electronic Countermeasures (ECM): Robust signal sampling and distribution.
Broadband Communication: Efficient power combining for high-capacity links.
Test & Measurement: Precise signal splitting for ultra-wideband system analysis.
PMDI's broadband couplers offer industry-leading performance over frequency bandwidths of up to 36:1. Each unit is built using high-reliability stripline technology housed in a rugged aluminum enclosure, ensuring stability across extreme environments.
Customization & Engineering
At PMDI, we understand that standard parts don't always fit specialized needs. We offer custom-engineered variations of our dividers and couplers to meet specific mechanical or electrical requirements upon request.
Model Number | No. of ways | Freq. Range | Insertion | Isolation | Amplitude | Phase | VSWR |
2-way | 2-18 GHz | 1.20dB | 18dB | ±0.30dB | ±5° | 1.50:1 | |
PD10124A2 | 2-way | 1-12.4 GHz | 1.50dB | 16dB | ±0.40dB | ±6° | 1.45:1 |
PD0520A2 | 2-way | 0.5-2.0 GHz | 0.50dB | 20dB | ±0.20dB | ±2° | 1.25:1 |
PD1040A2 | 2-way | 1.0-4.0 GHz | 0.50dB | 20dB | ±0.30dB | ±2° | 1.30:1 |
PD0825A2 | 2-way | 0.8-2.5 GHz | 0.40dB | 20dB | ±0.20dB | ±2° | 1.30:1 |
PD2080A2 | 2-way | 2.0-8.0 GHz | 0.60dB | 20dB | ±0.30dB | ±4° | 1.30:1 |
PD0560A2 | 2-way | 0.5-6 GHz | 1.20dB | 18dB | ±0.20dB | ±3° | 1.40:1 |
PD40180A2 | 2-way | 4.0-18.0 GHz | 0.80dB | 18dB | ±0.40dB | ±5° | 1.50:1 |
PD1080A2 | 2-way | 1-8 GHz | 1.20dB | 16dB | ±0.30dB | ±6° | 1.40:1 |
PD1020A2 | 2-way | 1-2 GHz | 0.35dB | 20dB | ±0.20dB | ±2° | 1.20:1 |
PD2040A2 | 2-way | 2-4 GHz | 0.35dB | 20dB | ±0.20dB | ±2° | 1.25:1 |
PD4080A2 | 2-way | 4-8 GHz | 0.50dB | 20dB | ±0.30dB | ±3° | 1.25:1 |
2-way | 0.5-18 GHz | 2.00dB | 14dB | ±0.50dB | ±5° | 1.50:1 | |
2-way | 2.0-18 GHz | 1.00dB | 16dB | ±0.20dB | ±2.5° | 1.40:1 | |
2-way | 2.0-18 GHz | 1.20dB | 16dB | ±0.30dB | ±5° | 1.50:1 | |
PD60180A2 | 2-way | 6-18 GHz | 0.70dB | 18dB | ±0.40dB | ±5° | 1.50:1 |
PD60180A2 | 2-way | 6-18 GHz | 0.70dB | 18dB | ±0.40dB | ±5° | 1.50:1 |
2-way | 0.5-20 GHz | 1.90dB | 17dB | ±0.30dB | ±4° | 1.50:1 | |
2-way | 2.0-40 GHz | 1.80dB | 18dB | ±0.40dB | ±4° | 1.30:1 | |
2-way | 5.0-40 GHz | 1.50dB | 15dB | ±0.40dB | ±6° | 1.60:1 | |
2-way | 10-40 GHz | 1.60dB | 14dB | ±0.50dB | ±5° | 1.60:1 | |
2-way | 18-40 GHz | 1.50dB | 18dB | ±0.30dB | ±4° | 1.60:1 | |
3-way | 0.5-20 GHz | 2.00dB | 18dB | ±0.60dB | ±6° | 1.60 :1 | |
3-way | 0.5-20 GHz | 0.70dB | 18dB | ±0.30dB | ±3° | 1.30 :1 | |
3-way | 0.5-20 GHz | 2.40dB | 17dB | ±0.50dB | ±5° | 1.50 :1 | |
PD2040A3 | 3-way | 2-4 GHz | 0.60dB | 18dB | ±0.30dB | ±5° | 1.30 :1 |
PD60180A3 | 3-way | 6-18 GHz | 1.20dB | 18dB | ±0.60dB | ±7° | 1.60:1 |
PD2018A3 | 3-way | 2-18 GHz | 1.80dB | 18dB | ±0.70dB | ±8° | 1.65:1 |
PD2018A4 | 4-way | 2-18 GHz | 2.20dB | 16dB | ±0.60dB | ±10° | 1.65:1 |
PD10124A4 | 4-way | 1-12.4 GHz | 2.80dB | 16dB | ±0.50dB | ±7° | 1.60:1 |
PD0560A4 | 4-way | 0.5-6 GHz | 2.20dB | 16dB | ±0.30dB | ±4° | 1.60:1 |
PD1080A4 | 4-way | 1-8 GHz | 2.20dB | 15dB | ±0.40dB | ±8° | 1.50:1 |
4-way | 0.5-2.0 GHz | 1.00dB | 20dB | ±0.20dB | ±3.0° | 1.30:1 | |
4-way | 0.5-2.0 GHz | 0.70dB | 20dB | ±0.20dB | ±2.5° | 1.30:1 | |
4-way | 0.5-20 GHz | 4.20dB | 18dB | ±0.40dB | ±5.0° | 1.60:1 | |
PD0825A4 | 4-way | 0.8-2.5 GHz | 0.70dB | 20dB | ±0.30dB | ±6° | 1.30:1 |
PD2080A4 | 4-way | 2.0-8.0 GHz | 1.20dB | 18dB | ±0.40dB | ±5° | 1.40:1 |
4-way | 2.0-18 GHz | 1.80dB | 18dB | ±0.25dB | ±6.0° | 1.70:1 | |
4-way | 2.0-18 GHz | 2.0dB | 18dB | ±0.6dB | ±10° | 1.60:1 | |
PD40180A4 | 4-way | 4.0-18.0 GHz | 1.60dB | 17dB | ±0.50dB | ±8° | 1.60:1 |
PD0510A4 | 4-way | 0.5-1 GHz | 0.60dB | 20dB | ±0.30dB | ±3° | 1.25:1 |
PD1020A4 | 4-way | 1-2 GHz | 0.60dB | 20dB | ±0.30dB | ±3° | 1.30:1 |
PD2040A4 | 4-way | 2-4 GHz | 0.60dB | 20dB | ±0.30dB | ±3° | 1.30:1 |
PD60180A4 | 4-way | 6-18 GHz | 1.30dB | 18dB | ±0.80dB | ±8° | 1.60:1 |
PD4080A4 | 4-way | 4-8 GHz | 0.80dB | 20dB | ±0.30dB | ±3° | 1.30:1 |
4-way | 18-40 GHz | 2.40dB | 18dB | ±0.50dB | ±5° | 1.70:1 | |
PD40180A8 | 8-way | 4.0-18.0 GHz | 2.50dB | 15dB | ±0.60dB | ±10° | 1.80:1 |
PD1020A8 | 8-way | 1-2 GHz | 1.00dB | 20dB | ±0.50dB | ±5° | 1.30:1 |
PD2040A8 | 8-way | 2-4 GHz | 0.90dB | 20dB | ±0.50dB | ±5° | 1.30:1 |
PD4080A8 | 8-way | 4-8 GHz | 1.20dB | 18dB | ±0.50dB | ±4° | 1.50:1 |
PD60180A8 | 8-way | 6-18 GHz | 2.20dB | 17dB | ±0.80dB | ±10° | 1.80:1 |
PD0560A8 | 8-way | 0.5-6 GHz | 3.20dB | 16dB | ±0.50dB | ±8° | 1.60:1 |
PD0520A8 | 8-way | 0.5-2.0 GHz | 1.50dB | 20dB | ±0.50dB | ±4° | 1.40:1 |
PD2018A8 | 8-way | 2-18 GHz | 3.50dB | 15dB | ±0.80dB | ±10° | 1.85:1 |
8-way | 18-40 GHz | 3.20dB | 18dB | ±0.60dB | ±6° | 1.7:1 | |
12-way | 6-18 GHz | 2.50dB | 14dB | ±1.00dB | ±10° | 1.80:1 |
